Basic Info.
Model NO.
20KVA To 1600KVA
Installation Method
Fixed
Stroke
Four Stroke
Cooling Method
Water Cooling
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Marine
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Ordinary
Excitation Mode
AC Rotating Exciter
Common Power
20kVA to 1600kVA
Rated Voltage
400/230V
Speed(Rpm)
1500rpm/1800rpm
Frequency
50Hz, 60Hz
Engine
Cummins
Alternator
Heyuan, Marathon, Leroy Somer, Stamford
Optional
Silent / Waterproof Canopy, ATS, Parallel System
Product Name
Diesel Generator
Generator Type
Open Type, Silent Type, Trailer Type
Color
Customized
Phase
One or Three Phases
Rated Speed
1500/1800
Starting Control Mode
Electric Starting
Mode of Transport
Sea Transportation
Certification
CE/ISO
Transport Package
Wooden Packing
Specification
According to diesel engine power
Trademark
For Cummins
Origin
China
HS Code
8502120000
Production Capacity
5000pieces/Year
Packaging & Delivery
Package Size
1000.00cm * 1000.00cm * 600.00cm
Package Gross Weight
2000.000kg
Product Description
Open Type Or Silent Canopy Electric Power Engine 50Hz 60Hz China Factory From Cummins Diesel Generator Set
| Power | Current/A | Engine model | Cylinder | Bore * Stroke | Displacement/L | Lube oil/L | Consumption/g/kw . h | Size | weight | |
| KW | KVA | |||||||||
| 30 | 37.5 | 54 | 4BT3.9-G2 | 4 | 102*120 | 3.9 | 10.9 | 212 | 1700*710*1110 | 750 |
| 40 | 50 | 72 | 4BTA3.9-G2 | 4 | 102*120 | 3.9 | 10.9 | 212 | 1800*750*1200 | 800 |
| 50 | 62.5 | 90 | 4BTA3.9-G2 | 4 | 102*120 | 3.9 | 10.9 | 212 | 1850*800*1300 | 820 |
| 64 | 80 | 115.2 | 4BTA3.9-G11 | 4 | 102*120 | 3.9 | 10.9 | 206 | 1850*800*1300 | 950 |
| 80 | 100 | 144 | 4BTA3.9-G13 | 4 | 102*120 | 3.9 | 10.9 | 210 | 1900*800*1300 | 980 |
| 90 | 1125 | 162 | 4BTAA3.9-G3 | 4 | 102*120 | 3.9 | 10.9 | 212 | 2000*800*1300 | 1000 |
| 120 | 150 | 216 | 6BTAA5.9-G2 | 6 | 102*120 | 5.9 | 16 | 208 | 2350*820*1200 | 1200 |
| 132 | 165 | 237.6 | 6BTAA5.9-G12 | 6 | 102*120 | 5.9 | 16 | 207 | 2300*870*1300 | 1350 |
| 150 | 187.5 | 270 | 6CTA8.3-G2 | 6 | 114*135 | 8.3 | 28 | 212 | 2390*900*1350 | 1465 |
| 180 | 225 | 324 | 6CTAA8.3-G2 | 6 | 114*135 | 8.3 | 24 | 205 | 2500*1050*1450 | 1580 |
| 200 | 250 | 360 | 6CTAA8.3-G9 | 6 | 114*135 | 8.3 | 24 | 204 | 2550*1050*1480 | 1700 |
| 200 | 250 | 360 | 6LTAA8.9-G2 | 6 | 114*145 | 8.9 | 28 | 197 | 2500*950*1500 | 1850 |
| 220 | 275 | 396 | 6LTAA8.9-G3 | 6 | 114*145 | 8.9 | 28 | 195 | 2600*970*1500 | 2000 |
| 250 | 312.5 | 450 | 6LTAA9.5-G3 | 6 | 116.5*148 | 9.5 | 32 | 193 | 2700*1100*1550 | 2100 |
| 280 | 350 | 504 | 6LTAA9.5-G1 | 6 | 116.5*148 | 9.5 | 32 | 199 | 2750*1150*1550 | 2000 |
| 400 | 500 | 720 | 6ZTAA13-G4 | 6 | 130*163 | 13 | 45 | 189 | 3200*1360*1950 | 3000 |
| 400 | 500 | 720 | QSZ13-G2 | 6 | 130*163 | 13 | 45 | 189 | 3150*1370*1900 | 3150 |
| 450 | 562.5 | 810 | QSZ13-G3 | 6 | 130*163 | 13 | 45 | 191 | 3150*1350*1860 | 3200 |
| 32 | 40 | 57.6 | QSB3.9-G33 | 4 | 102*120 | 3.9 | 10.9 | 208 | 1700*850*1300 | 900 |
| 50 | 62.5 | 90 | QSB3.9-G2 | 4 | 102*120 | 3.9 | 10.9 | 220 | 1750*850*1350 | 950 |
| 68 | 85 | 122.4 | QSB3.9-G3 | 4 | 102*120 | 3.9 | 10.9 | 212 | 1800*900*1400 | 960 |
| 80 | 100 | 144 | QSB3.9-G37 | 4 | 102*120 | 3.9 | 10.9 | 203 | 1850*900*1400 | 980 |
| 90 | 112.5 | 162 | QSB3.9-G39 | 4 | 102*120 | 3.9 | 10.9 | 203 | 1850*900*1500 | 980 |
| 90 | 112.5 | 162 | QSB5.9-G3 | 6 | 102*120 | 5.9 | 16.4 | 217 | 2160*800*1300 | 1050 |
| 120 | 150 | 216 | QSB5.9-G3 | 6 | 102*120 | 5.9 | 16.4 | 213 | 2200*800*1300 | 1100 |
| 120 | 150 | 216 | QSB5.9-G31 | 6 | 102*120 | 5.9 | 16.4 | 205 | 2200*800*1300 | 1100 |
| 132 | 165 | 237.6 | QSB5.9-G33 | 6 | 102*120 | 5.9 | 16.4 | 205 | 2200*800*1300 | 1100 |
| 150 | 187.5 | 270 | QSB5.9-G33 | 6 | 107*124 | 6.7 | 19.5 | 213 | 2300*850*1300 | 1450 |
| 160 | 200 | 288 | QSB6.7-G32 | 6 | 107*124 | 6.7 | 19.5 | 200 | 2300*850*1300 | 1450 |
| 180 | 225 | 324 | QSB6.7-G31 | 6 | 107*124 | 6.7 | 19.5 | 200 | 2300*850*1300 | 1450 |
| 200 | 250 | 360 | QSL8.9-G34 | 6 | 116.5*114.5 | 8.9 | 28 | 201 | 2640*970*1450 | 2000 |
| 200 | 250 | 360 | OSL8.9-G4 | 6 | 114*144.5 | 8.9 | 28 | 204 | 2650*1050*1450 | 2350 |
| 240 | 300 | 432 | QSL8.9-G33 | 116.5*114.5 | 8.9 | 28 | 210 | 2650*1050*1450 | 2350 | |
| 200 | 250 | 360 | MTA11-G2 | 6 | 125*147 | 11 | 37 | 196 | 2800*1050*1550 | 2100 |
| 200 | 250 | 360 | NT855-GA | 6 | 140*152 | 14 | 38 | 191 | 3000*1140*1820 | 2450 |
| 250 | 312.5 | 450 | NTA855-G1A | 6 | 140*152 | 14 | 38 | 193 | 3100*1150*1680 | 2475 |
| 280 | 350 | 504 | MTAA11-G3 | 6 | 125*147 | 11 | 38 | 185 | 2870*1150*1550 | 2700 |
| 280 | 350 | 504 | NTA855-G1B | 6 | 140*152 | 14 | 38 | 209 | 3100*1000*1700 | 2600 |
| 300 | 375 | 540 | NTA855-G2A | 6 | 140*152 | 14 | 38 | 191 | 3100*1150*1700 | 3000 |
| 320 | 400 | 576 | NTA855-G4 | 6 | 140*152 | 14 | 38 | 197 | 3150*1150*1700 | 3000 |
| 320 | 400 | 576 | NTA855-G7 | 6 | 140*152 | 14 | 38 | 207 | 3200*1050*1900 | 3150 |
| 350 | 437.5 | 630 | NTAA855-G7A | 6 | 140*152 | 14 | 38 | 200 | 3250*1100*1700 | 2900 |
| 400 | 500 | 720 | KTA19-G3 | 6 | 159*159 | 19 | 50 | 205 | 3500*1300*1950 | 3755 |
| 450 | 562.5 | 810 | KTA19-G3A | 6 | 159*159 | 19 | 50 | 202 | 3500*1380*1980 | 3890 |
| 450 | 562.5 | 810 | KTA19-G4 | 6 | 159*159 | 19 | 50 | 202 | 3500*1380*1980 | 3890 |
| 480 | 600 | 864 | KTAA19-G6 | 6 | 159*159 | 19 | 50 | 216 | 3500*1520*2100 | 3900 |
| 500 | 625 | 900 | KTA19-G8 | 6 | 159*159 | 19 | 50 | 209 | 3500*1520*1900 | 3900 |
| 500 | 625 | 900 | KTAA19-G5 | 6 | 159*159 | 19 | 50 | 204 | 3500*1600*1850 | 3900 |
| 530 | 662.5 | 954 | KAA19-G6A | 6 | 159*159 | 19 | 50 | 216 | 3600*1600*2060 | 3900 |
| 600 | 750 | 1080 | KT38-GA | 12 | 159*159 | 38 | 135 | 221 | 4300*1700*2350 | 6800 |
| 640 | 800 | 1152 | KTA38-G2 | 12 | 159*159 | 38 | 135 | 206 | 4300*1800*2500 | 7095 |
| 700 | 875 | 1260 | KTA38-G2B | 12 | 159*159 | 38 | 135 | 198 | 4300*1800*2350 | 7200 |
| 800 | 1000 | 1440 | KTA38-G2A | 12 | 159*159 | 38 | 135 | 203 | 4350*1760*2500 | 7300 |
| 824 | 1030 | 1483.2 | KTA38-G5 | 12 | 159*159 | 38 | 135 | 200 | 4320*1800*2250 | 7575 |
| 1000 | 1250 | 1800 | KTA38-G9 | 12 | 159*159 | 38 | 135 | 193 | 4550*1850*2350 | 8300 |
| 1000 | 1250 | 1800 | KTA50-G3 | 16 | 159*159 | 50 | 177 | 202 | 5000*2040*2430 | 8900 |
| 1200 | 1500 | 2160 | KTA50-G8 | 16 | 159*159 | 50 | 204 | 205 | 5350*2110*2450 | 9300 |
| 1200 | 1500 | 2160 | KTA50-GS8 | 16 | 159*159 | 50 | 204 | 205 | 5600*2150*2600 | 10300 |
| 1500 | 1875 | 2700 | KTA50-G15X | 16 | 159*159 | 50 | 204 | 204 | 5700*2280*2500 | 11500 |
| 220 | 275 | 396 | QSNT-G6 | 6 | 140*152 | 14 | 39 | 214 | 3100*1050*1750 | 2900 |
| 250 | 312.5 | 450 | QSNT-G7 | 6 | 140*152 | 14 | 39 | 214 | 3100*1050*1750 | 2900 |
| 280 | 350 | 504 | QSNT-G1 | 6 | 140*152 | 14 | 39 | 215 | 3150*1100*1800 | 2950 |
| 320 | 400 | 576 | QSNT-G2 | 6 | 140*152 | 14 | 39 | 210 | 3200*1100*1800 | 3000 |
| 350 | 437.5 | 630 | QSNT-G3 | 6 | 140*152 | 14 | 39 | 204 | 3200*1150*1950 | 3060 |
| 400 | 500 | 720 | QSNT-G4X | 6 | 140*152 | 14 | 39 | 211 | 3400*1250*1970 | 3200 |
| 450 | 562.5 | 810 | KTA19-G8E | 6 | 159*159 | 19 | 50 | 206 | 3390*1340*2000 | 4000 |
| 500 | 625 | 900 | KTA19-G8A | 6 | 159*159 | 19 | 50 | 205 | 3690*1550*2100 | 4050 |
| 500 | 625 | 900 | QSK19-G4 | 6 | 159*159 | 19 | 84 | 216 | 3650*1400*2400 | 4700 |
| 500 | 625 | 900 | QSK19-G18 | 6 | 159*159 | 19 | 84 | 206 | 3630*1660*2200 | 4600 |
| 550 | 687.5 | 990 | KTA19-G9A | 6 | 159*159 | 19 | 50 | 205 | 3980*1550*2100 | 4250 |
| 600 | 750 | 1080 | QSK19-G20 | 6 | 159*159 | 19 | 84 | 194 | 4300*1550*2100 | 5200 |
| 640 | 800 | 1152 | QSK19-G21 | 6 | 159*159 | 19 | 84 | 198 | 4300*1550*2100 | 5200 |
| 640 | 800 | 1152 | KTA38-G2E | 12 | 159*159 | 38 | 135 | 208 | 4480*1750*2460 | 6800 |
| 700 | 875 | 1260 | QSK38-G7 | 12 | 159*159 | 38 | 170 | 201 | 4600*1700*2300 | 7800 |
| 750 | 937.5 | 1350 | KTA38-G5E | 12 | 159*159 | 38 | 135 | 205 | 4800*1888*2376 | 7500 |
| 750 | 937.5 | 1350 | QSK38-G9 | 12 | 159*159 | 38 | 144 | 220 | 4650*1850*2460 | 7600 |
| 800 | 1000 | 1440 | KTA38-G5E | 12 | 159*159 | 38 | 135 | 205 | 4800*1888*2376 | 7500 |
| 800 | 1000 | 1440 | QSK38-G10 | 12 | 159*159 | 38 | 144 | 214 | 4800*1850*2330 | 7800 |
| 850 | 1062.5 | 1530 | KTA38-G7E | 12 | 159*159 | 38 | 135 | 203 | 5000*2140*2550 | 7100 |
| 900 | 1125 | 1620 | KTA38-G9E | 12 | 159*159 | 38 | 135 | 203 | 5000*2140*2550 | 7400 |
| 900 | 1125 | 1620 | QSK38-G11 | 12 | 159*159 | 38 | 117 | 255 | 4620*2030*2555 | 8200 |
| 1000 | 1250 | 1800 | KTA38-G9A | 12 | 159*159 | 38 | 135 | 193 | 4430*2005*2420 | 8300 |
| 1000 | 1250 | 1800 | KTA50-G3E | 16 | 159*159 | 50 | 177 | 202 | 5560*2130*2592 | 8900 |
| 1000 | 1250 | 1800 | QSK38-G5 | 12 | 159*159 | 38 | 170 | 208 | 4860*2150*2440 | 10500 |
| 1100 | 1375 | 1980 | KTA50-G7E | 16 | 159*159 | 50 | 177 | 203 | 5680*2140*2592 | 10000 |
| 1200 | 1500 | 2160 | KTA50-G8E | 16 | 159*159 | 50 | 177 | 203 | 5680*2140*2592 | 10000 |
| 1200 | 1500 | 2160 | QSK38-G14 | 12 | 159*159 | 38 | 117 | 198 | 4680*2030*2555 | 10000 |
| 1280 | 1600 | 2304 | QSK38-G15 | 12 | 159*159 | 38 | 117 | 197 | 4680*2030*2555 | 10500 |
| 1500 | 1875 | 2700 | KTA5O-G15A | 16 | 159*159 | 50 | 204 | 205 | 5480*2200*2895 | 11500 |
| 1600 | 2000 | 2880 | KTA50-G16A | 16 | 159*159 | 50 | 205 | 204 | 5480*2200*2895 | 13000 |
