Basic Info.
Method
Chemical Treatment
Usage
Industrial
Material Choosen
Carbon Steel, SS304
Flotation Method
Dissloved Air
Capacity
5-100m3/Hr
Standard
Air Tank
Competent
Pump & Air Compressor
Transport Package
Wooden Package
Specification
As to different model
Trademark
MYEP
Origin
China
Packaging & Delivery
Package Size
5000.00cm * 150.00cm * 2200.00cm
Package Gross Weight
20.000kg
Product Description
Product Information
DAF Dissolved Air Flotation is one of the most important projects to separate solid and liquid and the most effective ways to remove tiny suspended particles whose specific gravity is close to water. This equipment is widely applied for water supply and drainage projects.
Working Priciple
Air Flotation is composed of the air flotation tank, dissolved air system, retune pipe for dissolved air, release device for water with dissolved air, slag scraping device (type of combination, trussed or chain plate can be selected according to the requirements of the uses) and electric cabinet.
Product Paramenters
Components Display
Company Profile
Why Choose Us
Exhibition Show
FAQ
Q1. Are you a factory or a trading company?
A: We belong to a factory, so we can control every aspect of the product and provide best quality with lowest price for you.
Q2. How do you ship the goods and how long does it take to arrive?
A: Airline and sea shipping also optional. Shipping time depends on distance.
Q3. Can you provide sludge sample test data?
A: Yes, please give us detailed information including sludge type, solid content rate, etc. We will reply the test data asap.
Q4. Is it OK to print my logo on the product?
A: Yes, but inform us formally before our production.
Q5. Is there any other equipment used in sludge treatment?
A: Yes, including polymer dosing system, sludge thickener, conveying device, rotary drum screen, coarse screen, paddle dryer, dissolved air flotation, sludge scraper bridge and etc. If you are interested, contact us for further information.
DAF Dissolved Air Flotation is one of the most important projects to separate solid and liquid and the most effective ways to remove tiny suspended particles whose specific gravity is close to water. This equipment is widely applied for water supply and drainage projects.
Air Flotation is widely used in sewage treatment and water purification. The application is as follows:
1. Paper pulp and pure water recycle from paper making.
2. Remove all kinds of heavy metal ion.
3. Separation of sewage and greasy dirt from oil refining.
4. Remove impurities from tannery wastewater.
5. Remove color and impurities from printing and dyeing wastewater.
6. All kinds of bio-treatment, solid-liquid separation of biological mud membrane.
7. Sludge concentration (treatment capacity is 30% to 50% of the equipment capacity).
1. Paper pulp and pure water recycle from paper making.
2. Remove all kinds of heavy metal ion.
3. Separation of sewage and greasy dirt from oil refining.
4. Remove impurities from tannery wastewater.
5. Remove color and impurities from printing and dyeing wastewater.
6. All kinds of bio-treatment, solid-liquid separation of biological mud membrane.
7. Sludge concentration (treatment capacity is 30% to 50% of the equipment capacity).
Working Priciple
Air Flotation is composed of the air flotation tank, dissolved air system, retune pipe for dissolved air, release device for water with dissolved air, slag scraping device (type of combination, trussed or chain plate can be selected according to the requirements of the uses) and electric cabinet.
Product Paramenters
| Model | Capacity (m³/hr) | Motor Power (KW) | Dimension (L*W*H) |
| MPQF-5 | 5 | 3 | 3300*1800*2200 |
| MPQF-10 | 10 | 3 | 4000*2100*2200 |
| MPQF-20 | 20 | 7.5 | 4600*2400*2200 |
| MPQF-30 | 30 | 7.5 | 5200*2600*2400 |
| MPQF-40 | 40 | 7.5 | 6000*2600*2400 |
| MPQF-50 | 50 | 7.5 | 7000*2600*2400 |
| MPQF-60 | 60 | 7.5 | 7600*2800*2400 |
| MPQF-70 | 70 | 7.5 | 8400*2800*2400 |
| MPQF-80 | 80 | 7.5 | 9200*2800*2400 |
| MPQF-100 | 100 | 15 | 10000*2800*2600 |
Components Display
Company Profile
Why Choose Us
Exhibition Show
FAQ
Q1. Are you a factory or a trading company?
A: We belong to a factory, so we can control every aspect of the product and provide best quality with lowest price for you.
Q2. How do you ship the goods and how long does it take to arrive?
A: Airline and sea shipping also optional. Shipping time depends on distance.
Q3. Can you provide sludge sample test data?
A: Yes, please give us detailed information including sludge type, solid content rate, etc. We will reply the test data asap.
Q4. Is it OK to print my logo on the product?
A: Yes, but inform us formally before our production.
Q5. Is there any other equipment used in sludge treatment?
A: Yes, including polymer dosing system, sludge thickener, conveying device, rotary drum screen, coarse screen, paddle dryer, dissolved air flotation, sludge scraper bridge and etc. If you are interested, contact us for further information.
