Product Description
And can bear radial load and axial load of angular contact ball bearings, single row angular contact ball bearings can only endure single direction axial load, so it is often adopted to paired mounting. When used in pair has preload matched angular contact ball bearings are the most convenient.Retainers are made of brass, synthetic resins, with bearing form, conditions of use and distinction.
Model Number | Inner Diameter | Outer Diameter | Width |
(mm) | (mm) | (mm) | |
7304AC | 20 | 52 | 12 |
7305AC | 25 | 62 | 17 |
7306AC | 30 | 72 | 19 |
7307AC | 35 | 80 | 21 |
7308AC | 40 | 90 | 23 |
7309AC | 45 | 100 | 25 |
7310AC | 50 | 110 | 27 |
7311AC | 55 | 120 | 29 |
7312AC | 60 | 130 | 31 |
7313AC | 65 | 140 | 33 |
7314AC | 70 | 150 | 35 |
7315AC | 75 | 160 | 37 |
7316AC | 80 | 170 | 39 |
7317AC | 85 | 180 | 41 |
7318AC | 90 | 190 | 43 |
7319AC | 95 | 200 | 45 |
7320AC | 100 | 215 | 47 |
7322AC | 110 | 240 | 50 |
Model Number | Inner Diameter | Outer Diameter | Width |
(mm) | (mm) | (mm) | |
7305ACM | 25 | 62 | 17 |
7306ACM | 30 | 72 | 19 |
7307ACM | 35 | 80 | 21 |
7308ACM | 40 | 90 | 23 |
7309ACM | 45 | 100 | 25 |
7310ACM | 50 | 110 | 27 |
7311ACM | 55 | 120 | 29 |
7312ACM | 60 | 130 | 31 |
7313ACM | 65 | 140 | 33 |
7314ACM | 70 | 150 | 35 |
7315ACM | 75 | 160 | 37 |
7316ACM | 80 | 170 | 39 |
7317ACM | 85 | 180 | 41 |
7318ACM | 90 | 190 | 43 |
7319ACM | 95 | 200 | 45 |
7320ACM | 100 | 215 | 47 |
7322ACM | 110 | 240 | 50 |
7324ACM | 120 | 260 | 55 |
Model Number | Inner Diameter | Outer Diameter | Width |
(mm) | (mm) | (mm) | |
7405AC | 25 | 80 | 21 |
7406AC | 30 | 90 | 23 |
7407AC | 35 | 100 | 25 |
7408AC | 40 | 110 | 27 |
7409AC | 45 | 120 | 29 |
7410AC | 50 | 130 | 31 |
7411AC | 55 | 140 | 33 |
7412AC | 60 | 150 | 35 |
7413AC | 65 | 160 | 37 |
7414AC | 70 | 180 | 42 |
7415AC | 75 | 190 | 45 |
7416AC | 80 | 200 | 48 |
Model Number | Inner Diameter | Outer Diameter | Width |
(mm) | (mm) | (mm) | |
7406ACM | 30 | 90 | 23 |
7407ACM | 35 | 100 | 25 |
7408ACM | 40 | 110 | 27 |
7409ACM | 45 | 120 | 29 |
7410ACM | 50 | 130 | 31 |
7411ACM | 55 | 140 | 33 |
7412ACM | 60 | 150 | 35 |
7413ACM | 65 | 160 | 37 |
7414ACM | 70 | 180 | 42 |
7415ACM | 75 | 190 | 45 |
7416ACM | 80 | 200 | 48 |
7417ACM | 85 | 210 | 52 |
7418ACM | 90 | 225 | 54 |
Shandong Haina Bearing Co., Ltd. is an integrated company of industry and trade. Since its establishment, it has been committed to the research and development, production, and sales of high-end seven types of tapered roller bearings, British non-standard bearings, deep groove ball bearings, and outer spherical bearings. We can customize and adjust various types of bearings according to customer needs. The products are widely applicablein fields such as automobiles, mines, chemicals, metallurgy, reducers, engineering machinery, agricultural machinery, and electric motors.
Our company has advanced testing equipment, forming a production model of product serialization and mass production. We have a group of experienced and skilled management personnel, who have introduced advanced production equipment and measuringand testing equipment. From the purchase of bearing raw materials to the delivery of finished products, we strictly control the entire process, ensuring the quality of the products.The products have the characteristics of precision, low noise, high load-bearing capacity and long service life.
A: All bearing parts before the production and the production process, strict inspection by 100%, including crack detection, roundness, hardness,
roughness,and the geometry size, all bearing meet ISO international standard.
2. Can you tell me the bearing material?
A: We have chrome steel GCR15, stainless steel, ceramics and other materials.
3. How long is your delivery time?
A: If the goods are in stock, usually 5 to 10 days, if the goods are no stock for 15 to 20 days, according to the quantity to determine the time.
4. OEM and custom you can receive?
A: Yes, accept OEM, can also be customized according to samples or drawings for you.
