Basic Info.
Model NO.
PMX30-45A
Warranty
N/M
Customized
Customized
Layout
Horizontal
Cutting Material
Copper, Carbon Steel, Iron, Aluminum, Metal Alloy, Stainless Steel
Automatic Grade
Automatic
Power Source
Electric
Cutting Mode
Plasma Cutting
Cooling Way
Water Cooling
Control
Automatic
Style
Handheld
Shielding Gas
Argon Gas
Frequency Range
High Frequency
Electric Current
AC
Type
Fusion
Current
125A
Torch Model
Duramax Machine Torch
Cutting Type
Plasma
Plasma Accessories
Torch Nozzles & Electrode
Application
CNC Plasma Cutting Machine
Ampere
50A/80A/130A/200A/260A
Plasma Torch Style
Powermax125A Torch
Consumables
Cutting Electrode Nozzle
Consumables for Cutting Machine
Electrode Nozzle
Cutting Tools
Plasma Nozzles Electrode
Material
Copper Wire
Powermax Shield
Plasma Cutter Tips
Appliication
Cutting Steel Plate
Nozzle
220975/420158/420169
Plasma Consumables Shield
220971 220975 420158 420169
Transport Package
Carton Box
Specification
brass
Trademark
OEM
Origin
China
HS Code
8468900000
Packaging & Delivery
Package Size
6.70cm * 1.70cm * 1.70cm
Package Gross Weight
0.025kg
Product Description
China Manufacturer 420133 Swirl Ring for PMX 30 AIR Plasma Cutting Torch
What are plasma cutter consumables ?
What are plasma cutter consumables ?
Plasma cutter consumables are a set of components in your plasma cutter that gradually wear over time until they need to be replaced: they have a life cycle. The consumables are all found in the cutting torch itself, which is where most of the energy is focussed, and keeping track of wear and tear is a key part of maintaining an efficient machine that cuts well and lasts a long time. Plasma cutting torch consumables include: a swirl ring, electrode, nozzle, retaining cap, and shield cap.
Nozzle:
The nozzle focuses the plasma arc and the gas that surrounds it to make a clean and precise cut. A nozzle with a larger
opening is used for gouging, while a nozzle with a smaller opening is better able to direct the gas and so is used for fine, detailed work
| Part Number | 220892 |
|---|---|
| Item Weight | 7.4 ounces |
| Product Dimensions | 2 x 2 x 0.7 inches |
| Operatin Range | 65A-125A |
| Plasma Power Source | Powermax 125 |
| Material | Copper |
| Item Package Quantity | 5 |
Electrode:
The electrode is a narrow piece of copper containing hafnium (which is an excellent conductor of electricity). Its job is to receive the electrical current from a cathode block inside the torch to which it is connected, and to focus the charge through its tip, which causes it to arc onto the workpiece.
Retaining cap:
The retaining cap essentially holds all of the consumable parts of the torch together. As temperatures at this end of the machine are extremely high, it's not just the parts creating and focussing the arc that are worn down; the component holding them together also degrades over time.
| Part Number | 220936 |
|---|---|
| Item Weight | 2.46ounces |
| Product Dimensions | 4.72 x 3.15 x 1.57 inches |
| Operatin Range | 30A-125A |
| Plasma Power Source | Powermax 125 |
| Item Package Quantity | 5 |
Shield cap:
The shield is there to protect the torch and its other components from the sparks and molten metal that result from the plasmacutting process. It takes the brunt of the fallout so that wear to other components is minimised as much as possible.
| Part Number | 220976 |
|---|---|
| Item Weight | 1.76 ounces |
| Product Dimensions | 3.94 x 3.94 x 1.97Inches |
| Operatin Range | 105A-125A |
| Plasma Power Source | Powermax 125 |
| Item Package Quantity | 5 |
Swirl ring:
The function of the swirl ring is to spin the plasma gas which has two main results; 1, The spinning gas is gyroscopically stabilised a bit like a bullet making the plasma column less tendency to deflect.
| Part Number | 420133 |
|---|---|
| Item Weight | 0.317ounces |
| Product Dimensions | 2.68 x 2.05 x 1.06 Inches |
| Operatin Range | 105A-125A |
| Plasma Power Source | Powermax 45A/65A/85A/105A/125A |
| Item Package Quantity | 5 |
Established in 2017, ALLWINCNC are a manufacturing company specializing in the production of plasma and laser consumables.
We want to build long-term relationships with customers rather than developing one-off deals.
By providing our products to help you succeed in your endeavors.
The core idea of ALLWIN is our commitment to achieving mutual success for our customers, shareholders, and employees through collaboration.
Therefore we will provide you with an overview of all current and legacy Hypertherm plasma cutting systems, so you could see which option fits best your needs.
| No | Part No | Ref No | Description |
| 1 | 220478 | FM220478 | Electrode 30A |
| 2 | 220480 | FM220480 | Nozzle 30A |
| 3 | 420134 | FM420134 | Nozzle 30A AIR |
| 4 | 420132 | FM420132 | Electrode 30A AIR |
| 5 | 420116 | FM420116 | Shield 15-30A |
| 6 | 420114 | FM420114 | Retaining Cap 15-30A |
| 7 | 420118 | FM420118 | Nozzle 15-30A |
| 8 | 420120 | FM420120 | Nozzle 15-30A |
| 9 | 420133 | FM420133 | Swirl Ring 30A AIR |
| 10 | 420211 | FM420211 | Swirl Ring 15-30A |
| 11 | 220569 | FM220569 | Deflector 30A |
| 12 | 420135 | FM420135 | Retaining Cap 30A AIR |
| 13 | 420399 | FM420399 | Deflector 30A |
| 14 | 220669 | FM220669 | Electrode 45A |
| 15 | 220671 | FM220671 | Nozzle 45A |
| 16 | 220672 | FM220672 | Gouging Nozzle |
| 17 | 220718 | FM220718 | Unshielded Nozzle 45A |
| 18 | 220673 | FM220673 | Shield 45A |
| 19 | 220674 | FM220674 | Shield 45A |
| 20 | 220675 | FM220675 | Gouging Shield 45A |
| 21 | 220713 | FM220713 | Retaining Cap |
| 22 | 220719 | FM220719 | Retaining Cap |
| 23 | 220670 | FM220670 | Swirl Ring 45A |
| 24 | 228320 | FM228320 | Main body 45A |
