Basic Info.
Model NO.
TWB388
Usage
Special Excavator, Mining Excavator, GM Excavator
Bucket
Backhoe
Transmission
Mechanical Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.5~1.0m³
Size
Small-Scale
Certification
CE, ISO9001: 2000
Condition
New
Operating Weight
8200kg
Overall Dimension
6230*2365*3752mm
Wheel Base
2200mm
Min. Ground Clearance
300mm
Loader Bucket Capacity
1.0 M3
Backhoe Bucket Capacity
0.3 M3
Loader Lifting Capacity
2500kg
Loader Bucket Dumping Height
2650mm
Max. Digging Depth
4085mm
Engine Model
Yuchai Yc4a105z-T20
Rated Power
75kw
Steering Angle
36 Degree
Min. Turning Radius
6581mm
Gearbox
Fixed Shaft Power Transmission, 2f, 2r
Max.Speed
22km/H
Transport Package
by Container
Specification
2.5 TON
Trademark
TOPWIN
Origin
China
HS Code
8429590000
Production Capacity
1000 Units Per Month
Packaging & Delivery
Package Size
1.00cm * 1.00cm * 1.00cm
Package Gross Weight
8200.000kg
Product Description
China Manufacture Cheap Price for Sale 2.5ton mini Backhoe Excavators with Attachments Loader Backhoe Tractor Backhoe Loaders with CE
Backhoe Loader Standard Configurations:
TB388 backhoe loader
Loading bucket 1cbm,
Backhoe bucket 0.3cbm,
Yuchai YC4A105Z-T20 engine,
Fixed shaft power shift transmission, 2F/2R,
Dry axle, 4x4 drive,
Pilot control,
Cabin without Air-conditioning,
One unit by 1x40feet container
Optional:
Cummins 4BTA3.9-C100 (74KW) engine,
AC,
LCD display instrument panel,
Carraro transmission
TB388 backhoe loader
Loading bucket 1cbm,
Backhoe bucket 0.3cbm,
Yuchai YC4A105Z-T20 engine,
Fixed shaft power shift transmission, 2F/2R,
Dry axle, 4x4 drive,
Pilot control,
Cabin without Air-conditioning,
One unit by 1x40feet container
Optional:
Cummins 4BTA3.9-C100 (74KW) engine,
AC,
LCD display instrument panel,
Carraro transmission
Backhoe Loader main features:
The integral body frame with more stable operating condition, more suitable for digging work.
The excavating working structure is side shift type, higher strength, good structural stability; and the loading end adopt eight -bar linkage mechanism.
The boom adopts larger section, improving the rigidity and deformation resistance.standard excavator bucket with strengthened and thicker steel.
Rear and front body, with small rotary radius,hydraulic steering,comfy and convenient to operate. heavy duty hinge joint and hydraulic pipe protection.
Lifting enlarge operator cabin with secure glass and wide field, comfortable steering wheel, high quality seat and suitable joystick control.
The integral body frame with more stable operating condition, more suitable for digging work.
The excavating working structure is side shift type, higher strength, good structural stability; and the loading end adopt eight -bar linkage mechanism.
The boom adopts larger section, improving the rigidity and deformation resistance.standard excavator bucket with strengthened and thicker steel.
Rear and front body, with small rotary radius,hydraulic steering,comfy and convenient to operate. heavy duty hinge joint and hydraulic pipe protection.
Lifting enlarge operator cabin with secure glass and wide field, comfortable steering wheel, high quality seat and suitable joystick control.
Backhoe Loader attachments:
A tool for every job
Jack Hammer Or Breaking Hammer Or Breakers,
Quick Hitches,
Pallet Forks,
Fork Frame,
Auger Or Earth Drill,
Thumb Bucket,
Excavator Buckets,
Sweeper,
Grapple,
Ripper,
Rake,
Jaw Bucket,
Shovels,
Hand Held Tools,
Compactor,
Patch Planer
A tool for every job
Jack Hammer Or Breaking Hammer Or Breakers,
Quick Hitches,
Pallet Forks,
Fork Frame,
Auger Or Earth Drill,
Thumb Bucket,
Excavator Buckets,
Sweeper,
Grapple,
Ripper,
Rake,
Jaw Bucket,
Shovels,
Hand Held Tools,
Compactor,
Patch Planer
Backhoe loader specifications:
| Transport Dimension | Overall Operating Weight | 8200KG |
| mm L*W*H | 6230×2365×3752 | |
| Wheel base | 2200mm | |
| Min. Ground Clearance | 300mm | |
| Bucket Capacity | 1.0m3 | |
| Breakout Force | 38KN | |
| Loading Lifting Capacity | 2500KG | |
| Bucket Dumping Height | 2650mm | |
| Bucket Dumping Distance | 1025mm | |
| Digging Depth | 52mm | |
| Backhoe Capacity | 0.3 m3 | |
| Max. Digging Depth | 4085mm | |
| Swing Angle of Excavator Grab | 190 degree | |
| Max. Pulling Force | 39KN | |
| Engine | Model | YC4A105Z-T20 |
| Rated Power | 75KW | |
| Steering System | Model of Steering Device | BZZ5-250 |
| Steering Angle | ±36 degree | |
| Min. turning radius | 6581mm | |
| Pressure of the system | 12Mpa | |
| Axle | Manufacturer | Feicheng Axle Factory |
| Main Transmission Type | Double Reduction | |
| Final Reducer | Single Stage Final Reducer | |
| Rated Loader of Axle | 4/18.5t | |
| Torque Converter | Model | YJ280 |
| Type | Single-stage Three Elements | |
| Max. Efficiency | 84.40% | |
| Inlet Pressure | 0.4Mpa-0.55 Mpa | |
| Outlet Pressure | 1.2Mpa-1.5 Mpa | |
| Cooling Method | Oil-cooling Pressure Circulation | |
| Gearbox | Type | Fixed Shaft Power Transmission |
| Oil Pressure of Clutch | 1373Kpa-1569 Kpa | |
| Gears | Two Gears Ahead, Two Gears Astern | |
| Max.Speed | 22Km/h | |
| Tyre | Model | 14-17.5/19.5L-24 |
| Pressure of Front wheel | 0.22 Mpa | |
| Pressure of Back Wheel | 0.22 Mpa | |
| Brake System | Service Brake | Air Over Oil Caliper Brake |
| External Type | ||
| Self-regulation | ||
| Self-balance | ||
| Emergency Brake | Operation Power Implementing brake | |
| Manual Operation Power Terminating Brake | ||
| Hydraulic System | Digging Power of Excavator Grab | 46.5KN |
| Digging Power of Dipper | 31KN | |
| Bucket Lifting Time | 5.4S | |
| Bucket Lowering Time | 3.1S | |
| Bucket Discharge Time | 2.0S |
2 units of TWB388 backhoe loaders can be loaded in one 40feet HQ container.
Shandong Topwin Machinery Co.,Ltd. (TOPWIN for short) is the one-stop solution provider for construction machinery, mining machinery, agricultural machinery and logistic machinery in China.
With more than 10 years experience in this field, TOPWIN has served various clients from USA, Canada, Mexico, Brazil, Argentina, Australia, Indonesia, Kazakhstan, Russia, Zimbabwe, Mozambique, Zambia, South Africa, etc.. We are helping our clients to succeed in every project by offering high cost-effective and reliable machines. TOPWIN has enjoyed great reputations in road constructions, mining operations, farming, fertilizer manufacturing, etc.. That's why we get repeat purchases and more new clients from different countries and regions.
TOPWIN values high quality products and immediate response to clients' demand. We know how important it is for client to have a product that not only keeps on doing its job throughout the day, but also keeps on doing so for many years.
TOPWIN values high quality products and immediate response to clients' demand. We know how important it is for client to have a product that not only keeps on doing its job throughout the day, but also keeps on doing so for many years.
Q: Why TOPWIN?
A: With 10 years' exporting experience,TOPWIN has been a well known brand in the market, now you can see TOPWIN machines in more than 30 countries.
What we can provide:
Quality machines.
More competitive prices.
More timely and effective service.
Q: Can I test the machine before order?
A: Yes, we have dealers in Brazil, Australia, Slovenia, Sweden, Croatia, Poland, Serbia, Zambia, Mozambique, South Africa, Syria, etc. Please tell me your detailed address, then I would like to recommend the closest customer for you, then you could go to test.
Q: What is your delivery time?
A: The delivery time is around 20 working days. In peak season, the production time would take longer.
Q: What is the payment term?
A: Normally we accept 30% deposit by TT for production, 70% balance by TT before shipping. Or by sight LC.
Q: What color can I choose?
A: There are Yellow, Red, Blue, Black, White, Orange, and Green to choose. We can customize the color according to your color number.
Q: Can I see the production progress after order?
A: Yes, during production, we can have video call and we could take photos/videos for your reference.
Q: What kind of service can I get from you if I buy? How can I get parts?
A: We have 1 year warranty for each machine.Within 1 year warranty, if any parts failure caused by quality issues, the new parts would be sent to you free of charge within 5 working days. We have professional after sales department to support for you at any time.
