Basic Info.
Model NO.
UCFLU
Vibration
Z1V1, Z2V2, Z3V3
Tolerance
ABEC-1,ABEC-3,ABEC-5
Stock
Rich
Transport Package
Single Box+Carton Box+Pallet
Specification
P0, P2, P4, P5, P6
Trademark
BUGAO/NBKT
Origin
Ningbo
HS Code
8482102000
Production Capacity
5 Million
Product Description
Specification
The outer spherical ball bearing is actually a variant of the deep groove ball bearing, which is characterized in that the outer diameter outer surface of the outer ring ball is spherical, and can be fitted into the corresponding concave spherical surface of the bearing seat to serve as a centering function. The outer spherical bearing is mainly used to bear the radial and axial combined load mainly based on the radial load, and generally it is not suitable to bear the axial load alone.
This type of bearing can be fitted with inner ring (with full set of rollers and retainers) and outer ring
Related Bearings
Spherical ball bearing with seat is also designed to be self-aligning, easy to install, and have a double-structured seal that can operate in harsh environments. The bearing housing is generally cast molded. Commonly used seats are vertical seat (P), square seat (F), boss square seat (FS), boss circular seat (FC), diamond seat (FL), ring seat (C), slider seat, etc. T).
This type of bearing can be fitted with inner ring (with full set of rollers and retainers) and outer ring
Unit No. | Dimension (mm) | Bearing No. | Housing No. | Weight(kg) | |||||||||
| d | h | a | e | b | s | g | w | B | n | ||||
| UCPA201 | 12 | 30.2 | 76 | 52 | 40 | M10 | 15 | 62 | 31 | 12.7 | UC201 | PA201 | 0.6 |
| UCPA202 | 15 | 30.2 | 76 | 52 | 40 | M10 | 15 | 62 | 31 | 12.7 | UC202 | PA202 | 0.59 |
| UCPA203 | 17 | 30.2 | 76 | 52 | 40 | M10 | 15 | 62 | 31 | 12.7 | UC203 | PA203 | 0.58 |
| UCPA204 | 20 | 30.2 | 76 | 52 | 40 | M10 | 15 | 62 | 31 | 12.7 | UC204 | PA204 | 0.56 |
| UCPA205 | 25 | 36.5 | 84 | 56 | 38 | M10 | 15 | 72 | 34.1 | 14.3 | UC205 | PA205 | 0.83 |
| UCPA206 | 30 | 42.9 | 94 | 66 | 50 | M14 | 18 | 84 | 38.1 | 15.9 | UC206 | PA206 | 1.12 |
| UCPA207 | 35 | 47.6 | 110 | 80 | 55 | M14 | 20 | 95 | 42.9 | 17.5 | UC207 | PA207 | 1.48 |
| UCPA208 | 40 | 49.2 | 116 | 80 | 58 | M14 | 20 | 100 | 49.2 | 19 | UC208 | PA208 | 1.89 |
| UCPA209 | 45 | 54.2 | 120 | 90 | 60 | M14 | 25 | 108 | 49.2 | 19 | UC209 | PA209 | 1.98 |
| UCPA210 | 50 | 57.2 | 130 | 94 | 64 | M16 | 25 | 116 | 51.6 | 19 | UC210 | PA210 | 2.16 |
| UCPA211 | 55 | 63.5 | 140 | 104 | 66 | M16 | 25 | 125 | 55.6 | 22.2 | UC211 | PA211 | 3.26 |
| UCPA212 | 60 | 69.9 | 150 | 114 | 68 | M16 | 25 | 138 | 65.1 | 25.4 | UC212 | PA212 | 4.19 |
Related Bearings
Spherical ball bearing with seat is also designed to be self-aligning, easy to install, and have a double-structured seal that can operate in harsh environments. The bearing housing is generally cast molded. Commonly used seats are vertical seat (P), square seat (F), boss square seat (FS), boss circular seat (FC), diamond seat (FL), ring seat (C), slider seat, etc. T).
Application
1. Automatic controlling machine
2. Semi-conductor industry
3. General industry machinery
4. Medical equipment
5. Solar energy equipment
6. Machine tool
7. Parking system
8. High-speed rail and aviation transportation equipment, etc.
Packaging & Shipping for UCFLU series
| Packaging Detail | 1.Industrial Exporting Package 2. Individual plastic/Carton/pallet 3. As the customers' requirements |
| Delivery Detail | 30-45 days for normal order |
