Basic Info.
Structure and Working Principle
Brushless
Type
Gdm
Certification
ISO9001, CCC, CE, UL
Brand
Gpg, Vtv
Power
6W, 10W, 15W, 20W, 40W, 90W, 120W, 200W, 300W
Transport Package
Carton
Specification
G2BLD10-24GN-18S
Trademark
GPG
Origin
China
HS Code
850150
Production Capacity
500000pic/Month
Product Description
TaiBang Motor Industry Group Co., Ltd.
The main products is induction motor, reversible motor, DC brush gear motor, DC brushless gear motor , CH/CV big gear motors , Planetary gear motor ,Worm gear motor etc, which used widely in various fields of manufacturing pipelining, transportation, food, medicine, printing, fabric, packing, office, apparatus, entertainment etc, and is the preferred and matched product for automatic machine.
Brushless DC motor is made up of motor and driver,which is a kind of typical product of mechanical and electrical integration.
It is highly regarded by market as its small volume,low noise,high efficiency,wide range of speed control and steady working state with less inaccuracy.The product is widely used in transmission equipment,textile machinery and medical devices,etc.
Motor Model Instruction
G2BLD15-24GN-18S
Motor Performance Parameter
Gearhead Model Instruction
2GN-100K
External Dimension
Should you have any questions,please feel free to contact Ms Susan Liu directly.
Let's talk in detail.
FAQ
Q: How about your company?
A:We are gear motor factory located in Wenzhou city of China.We start from 1995.We have more than 1200 workers.Main products is AC micro gear motor 6W to 250W, AC small gear motor 100W to 3700W,brush DC motor 10W to 400W,brushless motor 10W to 750W,drum motor 60W to 3700W,planetary gearbox ,worm gearbox etc .
Q: How to choose a suitable motor?
A:If you have gear motor pictures or drawings to show us, or you tell us detailed specs like voltage, speed, torque, motor size, working mode of the motor, needed lifetime and noise level etc.Please do not hesitate to let us know, then we can suggest suitable motor per your request .
Q: Can you make the gear motor with customize specifications ?
Yes, we can customize per your request for the voltage, speed, torque and shaft size and shape. If you need additional wires or cables soldered on the terminal or need to add connectors, or capacitors or EMC we can make it too.
Q: What's your lead time?
A: Usually our regular standard product will need 10-15days, a bit longer for customized products. But we are very flexible on the lead time, it will depend on the specific orders.
Q: What is your MOQ?
A: If delivery by sea ,the minimum order is 100 pieces, if deliver by express, there is no limit.
Q: Do you have the item in stock?
A: I am sorry we do not have the item in stock, All products are made with orders.
Q: How to contact us ?
A: You can send us enquiry .
The main products is induction motor, reversible motor, DC brush gear motor, DC brushless gear motor , CH/CV big gear motors , Planetary gear motor ,Worm gear motor etc, which used widely in various fields of manufacturing pipelining, transportation, food, medicine, printing, fabric, packing, office, apparatus, entertainment etc, and is the preferred and matched product for automatic machine.
Brushless DC motor is made up of motor and driver,which is a kind of typical product of mechanical and electrical integration.
It is highly regarded by market as its small volume,low noise,high efficiency,wide range of speed control and steady working state with less inaccuracy.The product is widely used in transmission equipment,textile machinery and medical devices,etc.
Motor Model Instruction
G2BLD15-24GN-18S
| G | 2 | BLD | 15 | 24 | GN | 18S |
| Factory Code | Frame Size | Motor Type | Output Power | Power Voltage | Motor Shaft Type | Motor Speed |
| GPG | Motor Mounting Flange: 60mm,70mm,80mm, 90mm,100mm,ø45,ø60 | BLD:Brushless Motor With Square Gearhead BLDP:Brushless Motor With Planetary Gearhead | 10:10W 15:15W 25:25W 40:40W 60:60W 90:90W 200:200W 400:400W | 24:DC24V 36:DC36V 48:DC48V 110:DC110V 220:DC220V | GN:General Bevel Gear GU:Reinforced Bevel Gear A1:Milling Keyway A:Flat type | 15S:1500RPM 18S:1800RPM 25S:2500RPM 30S:3000RPM |
Motor Performance Parameter
| Model | Voltage | Rated Power | No-load Parameter | Load Parameter | Motor Life (Hours) | Motor Weight(kg) | |||
| Rotation Speed | Current(A) | Rotation Speed | Torque(N.m) | Current(A) | |||||
| G2BLD15-24A(GN) | 24V | 15W | 2200RPM | Max 0.3 | 1800RPM | 0.05 | 1.1 | >5000 | 0.45 |
| G2BLD15-36A(GN) | 36V | 2100RPM | Max 0.2 | 1800RPM | 0.05 | 0.7 | |||
| G2BLD15-48A(GN) | 48V | 2100RPM | Max 0.1 | 1800RPM | 0.05 | 0.5 | |||
| G2BLD25-24A(GN) | 24V | 25W | 3300RPM | Max 0.4 | 3000RPM | 0.08 | 1.3 | 0.65 | |
| G2BLD25-36A(GN) | 36V | 3200RPM | Max 0.3 | 3000RPM | 0.08 | 0.9 | |||
| G2BLD25-48A(GN) | 48V | 3200RPM | Max 0.2 | 3000RPM | 0.08 | 0.7 | |||
Gearhead Model Instruction
2GN-100K
| 2 | GN | 100 | K |
| Dimension | Gear Type | Reduction Ratio | Bearing type |
| 2:60mm 3:70mm 4:80mm 5:90mm 6:104mm | GN:General Bevel Gear GU:Reinforced Bevel Gear | 1:100 | Ball Bearinig |
External Dimension
| Motor Type | Gearhead Type | Gear Ratio | L Dimension |
| G2BLD15-24GN G2BLD15-36GN G2BLD15-48GN | 2GN( )K | 1:3~1:20 | 32mm |
| 1:25~1:180 | 40mm |
Should you have any questions,please feel free to contact Ms Susan Liu directly.
Let's talk in detail.
FAQ
Q: How about your company?
A:We are gear motor factory located in Wenzhou city of China.We start from 1995.We have more than 1200 workers.Main products is AC micro gear motor 6W to 250W, AC small gear motor 100W to 3700W,brush DC motor 10W to 400W,brushless motor 10W to 750W,drum motor 60W to 3700W,planetary gearbox ,worm gearbox etc .
Q: How to choose a suitable motor?
A:If you have gear motor pictures or drawings to show us, or you tell us detailed specs like voltage, speed, torque, motor size, working mode of the motor, needed lifetime and noise level etc.Please do not hesitate to let us know, then we can suggest suitable motor per your request .
Q: Can you make the gear motor with customize specifications ?
Yes, we can customize per your request for the voltage, speed, torque and shaft size and shape. If you need additional wires or cables soldered on the terminal or need to add connectors, or capacitors or EMC we can make it too.
Q: What's your lead time?
A: Usually our regular standard product will need 10-15days, a bit longer for customized products. But we are very flexible on the lead time, it will depend on the specific orders.
Q: What is your MOQ?
A: If delivery by sea ,the minimum order is 100 pieces, if deliver by express, there is no limit.
Q: Do you have the item in stock?
A: I am sorry we do not have the item in stock, All products are made with orders.
Q: How to contact us ?
A: You can send us enquiry .
